Tietjen Impact-Classifier Mill TICM
Ultrafine grinding of fish and shrimp feed
- Fineness of up to 98% < 200 µm possible
- Optimal quality of extruded pellets thanks to homogeneous particle structure
- Energy-efficient fine grinding, no hammer mill required for pre-grinding
- Optimised design for temperature-sensitive products
Recommended for
Best Grinding Performance for Fish and Shrimp Feed
The Impact-Classifier Mill type TICM is designed for super fine grinding in fish and shrimp-feed production. It combines efficient impact grinding with precise classification in a single machine. The decisive advantage of the TICM is its narrow particle size distribution with accurate separation from 100 µm to 400 µm.
Take Advantage of these Benefits
Efficient Grinding with Very High Fineness Requirements
- Specially designed for the requirements of ultra-fine grinding
- Optimised design for temperature-sensitive products
- Integrated air classifier to control the maximum particle size as well as for a narrow grist spectrum
- Direct drive for energy efficiency
- Grinding disc and classifier wheel driven separately, different speeds possible
- Variable grist spectrum by changing the speeds of grinding disc and classifier wheel (when using a frequency converter)
Reliable Operation and Long Service Life
- Robust welded steel construction for continuous industrial operation (24/7)
- Grinding chamber equipped with wear elements to protect the housing, easy to change
High Availability with Low Downtimes
- Split, swiveling mill housing for quick accessibility and easy maintenance
- Low-maintenance direct drive
High Safety of Personnel and Plant
- Temperature and pressure measurement before and after the mill
- Pressure shock resistant design according to PSR 11 optionally possible
- ATEX design of the electrical components optionally possible
Technical Data
Machine types
| Impact mill | TICM 800 | TICM 1000 | TICM 1300 | TICM 1600 |
| Drive mill (kW) | 75 kW | 100 kW | 160 kW | 250 kW |
| Drive classifier (kW) | 5.5 kW | 11 kW | 15 kW | 37 kW |
| Filter system | ||||
| Filter area (m³) | 70 m³ | 102 m³ | 158 m³ | 214 m³ |
| Air volume (m³/min) | 96 m³/min | 150 m³/min | 240 m³/min | 380 m³/min |
| Fan drive (kW) | 90 kW | 110 kW | 160 kW | 250 kW |
| Grinding capacity (Reference values for typical fish feed recipes with max. 8 % fat incl. rework, deviations possible depending on the recipe) | ||||
| Fineness 98 % < 100 µm, d 98 (t/h) | 0,75 t/h | 1,2 t/h | 1,9 t/h | 3 t/h |
| Fineness 98 % < 200 µm, d 98 (t/h) | 2 t/h | 3,5 t/h | 5 t/h | 8,5 t/h |
| Fineness 98 % < 300 µm, d 98 (t/h) | 3 t/h | 5 t/h | 7,5 t/h | 11,5 t/h |
| Fineness 98 % < 400 µm, d 98 (t/h) | 4 t/h | 6 t/h | 9 t/h | 14,5 t/h |
